SL 17 SMD 109 10 G B TR

Headers, Male Pins Overview

The Fischer Elektronik SL 17 SMD 109 10 G B TR is a surface mount male header connector featuring ten positions with a 2.54 mm (0.100 inch) pitch. It utilizes gold-plated contacts for reliable signal transmission and operates within a temperature range of -40°C to +163°C. The component is designed for automated assembly, supplied in a tape-and-reel configuration with a reel diameter of 330 mm. Constructed with glass-fiber reinforced polyamide insulation, it ensures mechanical stability and thermal resistance during soldering processes.

Headers, Male Pins Feature Summary

• Surface mount design optimized for automated pick-and-place assembly
• Gold-plated contact surfaces ensure corrosion resistance and stable electrical performance
• High-temperature resistant polyamide insulation supports standard reflow soldering profiles

Headers, Male Pins Applications

• Automated PCB assembly lines requiring tape-and-reel components
• High-density electronic interconnects in consumer devices
• Industrial control systems operating under moderate thermal stress

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix 'B TR' confirms the tape-and-reel packaging format required for automatic insertion equipment. Ensure the reel diameter specification matches your feeder system capabilities. Confirm that the gold plating thickness meets your conductivity requirements. Cross-reference the pin count and pitch against your PCB footprint design to prevent alignment errors during manufacturing.

Headers, Male Pins Selection Notes

Select this part when surface mount technology is mandatory for high-volume production. The 2.54 mm pitch offers a balance between density and manufacturability. Consider the thermal rating if the application involves prolonged exposure to elevated temperatures. The gold finish is suitable for environments where oxidation resistance is critical for long-term reliability.

Headers, Male Pins Part Context

This component belongs to the SL 17 SMD series of male headers from Fischer Elektronik. The series provides various position counts and packaging options to suit different assembly needs. The SL 17 line is characterized by its robust construction and compatibility with standard surface mount processes, making it a common choice for modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.54 mm pitch, 10-position count, and surface mount form factor. Verify that alternative suppliers offer identical gold-plated contacts and compatible insulation materials. Ensure any replacement part supports the same thermal operating range and soldering profile requirements.
