SL 2 078 38 Z

Headers, Male Pins Overview

The SL 2 078 38 Z is a single-row male pin header connector manufactured by Fischer Elektronik. It features 38 positions with a 0.100 inch (2.54 mm) pitch, designed for through-hole mounting. The contacts are tin-plated copper alloy pins. The connector has an overall contact length of 0.547 inches (13.90 mm), with a mating contact length of 0.319 inches (8.10 mm) and a post length of 0.118 inches (3.00 mm). The insulation height is 0.110 inches (2.80 mm).

Headers, Male Pins Feature Summary

• Single row configuration with square-shaped male pins.
• Through-hole termination method for PCB integration.
• Tin-plated contact surfaces for corrosion resistance.

Headers, Male Pins Applications

• General purpose board-to-board interconnections.
• Wire-to-board connections in electronic assemblies.
• Industrial control panel wiring.

Headers, Male Pins Procurement Notes

Verify the specific suffix 'Z' corresponds to the tin-plated finish as documented in official datasheets. Confirm that the 38-position count matches the required circuit density. Ensure the through-hole footprint aligns with the target PCB design specifications before procurement.

Headers, Male Pins Selection Notes

Select this component when a single-row, 2.54mm pitch header is required. The tin plating offers a cost-effective solution for standard applications. Consider the physical dimensions, particularly the 13.90mm total length, to ensure adequate clearance within the enclosure or assembly space.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL series of rectangular connectors. It is categorized under headers and male pins. The product is currently active and available for production use. It serves as a standard interconnect solution within the manufacturer's broader portfolio of PCB connectors.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 38-position count, 2.54mm pitch, and through-hole mounting style. Verify compatibility of the tin-plated contact finish with mating connectors. Cross-reference mechanical dimensions to ensure fit within existing PCB layouts.
