SL 2 154 60 Z

Headers, Male Pins Overview

The Fischer Elektronik SL 2 154 60 Z is a two-row male pin header connector designed for through-hole mounting. It features 60 positions with a 0.635 mm (0.025 inch) pitch and a 2.00 mm row spacing. The contacts are tin-plated copper alloy, providing a low contact resistance of less than 5 mΩ. Rated for 3 A at 250 V AC, the unit utilizes PA 4.6 insulation with UL 94 V-0 flammability rating. Operating temperature ranges from -40°C to +163°C, supporting soldering at 260°C for 10 seconds.

Headers, Male Pins Feature Summary

• Two-row configuration with precise 0.635 mm pitch for high-density interconnects
• Tin-plated copper alloy contacts ensuring reliable electrical performance
• PA 4.6 insulation material offering thermal stability and flame resistance

Headers, Male Pins Applications

• Industrial control system signal routing
• Test and measurement equipment interfaces
• Consumer electronics board-to-board connections

Headers, Male Pins Procurement Notes

Verify the specific suffix 'Z' indicates tin plating as per official datasheets. Confirm mechanical dimensions match PCB layout requirements. Ensure compatibility with mating female connectors in the same series. Check insulation color and flammability ratings against application standards.

Headers, Male Pins Selection Notes

Select this model when high-density two-row interconnection is required with standard through-hole assembly. Consider the 3 A current rating and 250 V voltage limit for circuit design. Evaluate thermal endurance up to 163°C for environments requiring robust heat resistance during operation or reflow processes.

Headers, Male Pins Part Context

Part of the Fischer Elektronik SL 2 series, which offers various pin counts and configurations. This specific variant provides a balanced solution for applications needing moderate density without excessive height. It complements other headers in the family differing only in pole count or plating finish.

Headers, Male Pins Replacement Considerations

Direct substitutes must maintain identical 0.635 mm pitch, two-row layout, and 60-position count. Verify that alternative components support the same 3 A current rating and through-hole termination method. Ensure insulation material compatibility with existing thermal profiles.
