SL 2 230 32 S

Headers, Male Pins Overview

The Fischer Elektronik SL 2 230 32 S is a board connector featuring 32 contacts arranged in two rows. It utilizes a male pin configuration with a 2.54 mm (0.100 inch) terminal pitch and a row spacing of 2.00 mm. The component is designed for straight through-hole mounting on printed circuit boards. Contact surfaces are finished with gold plating to ensure reliable electrical performance. The housing material meets UL 94 V-0 flammability standards, providing necessary insulation properties for general-purpose electronic applications.

Headers, Male Pins Feature Summary

• Two-row male header design for high-density interconnection
• Gold-plated contact surfaces for enhanced conductivity and corrosion resistance
• Straight through-hole termination method for secure PCB attachment
• UL 94 V-0 rated housing material for fire safety compliance

Headers, Male Pins Applications

• General-purpose electronic circuit interconnections
• Board-to-board connectivity systems
• Industrial control panel wiring
• Consumer electronics assembly

Headers, Male Pins Procurement Notes

Verify the specific part number SL 2 230 32 S against official Fischer Elektronik documentation to confirm contact count and row configuration. Ensure compatibility with existing PCB footprint designs regarding the 2.54 mm pitch and 2.00 mm row spacing. Check for RoHS compliance status if required by project specifications. Confirm that the gold plating specification matches the application's environmental requirements.

Headers, Male Pins Selection Notes

Select this component when a two-row male header with 32 positions is required for through-hole assembly. Consider the 2.54 mm pitch standard for widespread availability of mating connectors. Evaluate the gold contact finish for long-term reliability in environments where oxidation resistance is critical. Verify mechanical dimensions fit within the available board space constraints.

Headers, Male Pins Part Context

This component belongs to the Fischer Elektronik SL series of precision-engineered electronic connectors. The series offers various configurations tailored for different board connection needs. The SL 2 230 32 S specifically addresses applications requiring a compact yet robust two-row interface. Its design emphasizes standardization while maintaining high-quality construction materials for durability.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 32-position, two-row, 2.54 mm pitch specification. Verify that alternative parts maintain the same straight through-hole mounting style and gold contact finish. Ensure dimensional compatibility with the original PCB layout before substitution.
