SL 20 THR 112 16 S

Headers, Male Pins Overview

The SL 20 THR 112 16 S is a male pin header connector from the Fischer Elektronik SL 20 THR series. It features a single row with 16 positions and a 2.54 mm pitch. The connector utilizes Through-Hole Reflow (THR) technology for PCB mounting. Contact surfaces are gold-plated over nickel, with a minimum gold thickness of 0.2 µm. It operates within a temperature range of -40°C to +163°C and withstands reflow soldering at 260°C for 10 seconds.

Headers, Male Pins Feature Summary

• Through-Hole Reflow compatible construction for automated assembly
• Gold-over-nickel contact plating for reliable conductivity
• Single-row male pin configuration

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnects
• Consumer electronics manufacturing using surface-mount reflow processes
• Automotive electronic modules needing high-temperature stability

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'S' denotes the gold-plated variant as per the datasheet. Confirm the 16-position count matches the design requirement. Ensure the PCB footprint supports the THR soldering profile. Check for UL 94 V-0 flammability rating compliance if required by the application standards. Validate the operating temperature range against environmental conditions.

Headers, Male Pins Selection Notes

Choose this component when through-hole reflow assembly is preferred over wave soldering for single-row headers. Select based on the need for gold plating in corrosive or high-cycle environments. Consider the 2.54 mm pitch compatibility with existing mating connectors. Evaluate the thermal resistance up to 163°C for high-heat applications. Compare against standard tin-plated versions if cost is a primary constraint.

Headers, Male Pins Part Context

This part belongs to the SL 20 THR series of Fischer Elektronik pin headers. The series is designed for high-reliability applications where reflow soldering is necessary. The SL 20 THR line offers various pole counts and plating options. This specific model represents a mid-range position count with premium contact materials.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.54 mm pitch, 16 positions, and THR mounting style. Verify that alternative parts support the same 260°C/10s reflow profile. Ensure comparable gold plating thickness if corrosion resistance is critical. Check dimensional compatibility with existing PCB footprints and mating cables.
