SL 20 THR 124 32 Z

Headers, Male Pins Overview

The SL 20 THR 124 32 Z is a male pin header connector manufactured by Fischer Elektronik. It features a 2.54 mm (0.100 inch) pitch and provides 32 positions in a single row configuration. Designed for Through-Hole Reflow (THR) soldering, this component supports board-to-board and wire-to-board connections. The connector is rated for a nominal current of 3 A and includes specific plating options such as gold or tin variants.

Headers, Male Pins Feature Summary

• Engineered specifically for Through-Hole Reflow (THR) soldering processes to ensure reliable mechanical and electrical joints.
• Constructed with precision contacts offering low volume resistance for efficient signal and power transmission.
• Compliant with UL 94 V-0 flammability standards for enhanced safety in electronic assemblies.

Headers, Male Pins Applications

• Board-to-board interconnections in multi-layer PCB designs
• Wire-to-board connections for peripheral integration
• Through-hole reflow assembly in consumer electronics

Headers, Male Pins Procurement Notes

Verify the exact contact plating specification required for your application, as the product line offers variations including Ni+Au and Ni+Sn finishes. Confirm that the chosen variant meets the thermal profile requirements for your specific reflow soldering process. Ensure the 32-position count aligns with your circuit design before finalizing the order.

Headers, Male Pins Selection Notes

Select this component when a standard 2.54 mm pitch male header is needed for through-hole reflow manufacturing. The 32-position format suits applications requiring moderate I/O density. Consider the specific insulation resistance and temperature range (-40°C to +163°C) to ensure compatibility with the operating environment of the target device.

Headers, Male Pins Part Context

This part belongs to the SL 20 THR 124 series of pin headers from Fischer Elektronik. The series is characterized by its reliability and accessibility, designed to meet the demands of modern surface mount and through-hole hybrid assembly techniques. It serves as a standard interface solution within the manufacturer's broader connector portfolio.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other models within the SL 20 THR 124 series with different pin counts, such as SL 20 THR 124 33 Z or SL 20 THR 124 14 Z, provided the pitch and mounting style remain consistent.
