SL 21 THR 164 2 Z

Headers, Male Pins Overview

The SL 21 THR 164 2 Z is a male pin header connector manufactured by Fischer Elektronik. It features a through-hole mounting style with a straight orientation. The connector has a pitch of 0.100 inches (2.54 mm) and consists of two rows. It contains a total of two contacts, providing a single position configuration for board-to-board or wire-to-board connections.

Headers, Male Pins Feature Summary

• Through-hole mounting design for secure PCB attachment
• Straight pin orientation for standard profile applications
• Dual-row configuration with 2.54 mm spacing

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• General electronic circuit assembly

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm row count and contact quantity. Ensure the through-hole variant matches the target PCB layout requirements. Confirm that the straight pin orientation aligns with mechanical constraints. Cross-reference the manufacturer part number against official Fischer Elektronik documentation to validate specifications before procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile, two-position connection is required. The 2.54 mm pitch ensures compatibility with standard breadboard and prototyping systems. Consider the through-hole method for robust mechanical stability compared to surface mount alternatives. Verify that the current rating meets the application's electrical demands.

Headers, Male Pins Part Context

This component belongs to the SL 21 THR series of male pin headers from Fischer Elektronik. The series offers various pole counts and row configurations. These connectors are designed for reliable signal transmission in compact electronic assemblies. The manufacturer provides extensive options within this family for different connectivity needs.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Fischer Elektronik headers with identical 2.54 mm pitch and through-hole mounting. Ensure replacement parts maintain the same two-row, two-contact configuration. Verify mechanical dimensions match the existing PCB footprint to ensure proper fit.
