SL 22 097 26 Z

Headers, Male Pins Overview

The SL 22 097 26 Z is a pin header connector from the Fischer Elektronik SL 22 097 series. It features a 2.54 mm pitch spacing and consists of 26 contacts arranged in two rows. The component utilizes through-hole termination for PCB mounting. Contact surfaces are tin-plated, providing reliable electrical connections. The connector supports board-to-board and wire-to-board applications within specified thermal limits.

Headers, Male Pins Feature Summary

• Dual-row configuration with 2.54 mm pitch spacing
• Tin-plated contact surfaces for corrosion resistance
• Through-hole mounting for secure PCB attachment

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Wire-to-board connection assemblies
• General electronic circuit integration

Headers, Male Pins Procurement Notes

Verify the specific suffix 'Z' confirms tin plating rather than gold or nickel variants. Ensure the 26-position count matches the required circuit density. Confirm that the dual-row layout aligns with the target PCB footprint dimensions. Check compatibility with mating connectors in the same series to guarantee proper engagement and mechanical stability during operation.

Headers, Male Pins Selection Notes

Select this model when a dual-row header with 26 positions is required. The 2.54 mm pitch is standard for many legacy and modern designs. Tin plating offers cost-effective conductivity suitable for general-purpose use. Consider the physical height and row spacing constraints of the assembly space before finalizing the design integration.

Headers, Male Pins Part Context

This part belongs to the SL 22 097 series of precision-engineered headers. Fischer Elektronik manufactures these components in Germany. The series includes various position counts and plating options. The SL 22 097 26 Z specifically denotes the 26-pin variant with tin finish, distinguishing it from other configurations in the product line.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Fischer Elektronik headers with identical 2.54 mm pitch and 26-position dual-row layouts. Verify that alternative parts match the through-hole termination style and tin plating specification. Ensure mechanical dimensions such as overall height and row spacing are equivalent to maintain assembly integrity.
