SL 22 316 56 G

Headers, Male Pins Overview

The SL 22 316 56 G is a board-to-board connector header manufactured by Fischer Elektronik. It features a two-row configuration with 56 positions and a 0.100-inch (2.54 mm) pin spacing. The component utilizes gold-plated contacts for reliable signal transmission. Designed for through-hole mounting, it includes male pins suitable for stacking applications. The housing is constructed from PA 4.6 material rated UL 94 V-0. Electrical specifications include a current rating of 3 A and voltage ratings of 250 V AC and 2000 V isolation.

Headers, Male Pins Feature Summary

• Two-row male header design for high-density interconnects
• Gold-plated CuSn alloy contacts ensuring low resistance
• Through-hole soldering termination method
• UL 94 V-0 flame retardant housing material

Headers, Male Pins Applications

• Board-to-board stacking connections
• High-density electronic assembly interfaces
• Precision-engineered circuit board interconnects

Headers, Male Pins Procurement Notes

Verify the specific part number SL 22 316 56 G against official Fischer Elektronik documentation to confirm contact count and plating specifications. Ensure compatibility with mating receptacles regarding pitch and row configuration. Check for any ordering suffixes that may indicate variations in housing color or contact finish. Confirm RoHS compliance status if required for your manufacturing process.

Headers, Male Pins Selection Notes

Select this component when a 56-position, two-row male header is required for PCB stacking. The 2.54 mm pitch ensures standard compatibility with industry connectors. Verify mechanical clearance requirements for the 0.635 mm contact height. Consider the 3 A current rating for power distribution needs within the assembly.

Headers, Male Pins Part Context

This component belongs to the SL 22 316 series of board connectors from Fischer Elektronik. The series offers various pin counts and configurations for different density requirements. These headers are designed for robust electrical connections in compact electronic devices. The product line emphasizes precision engineering and reliable performance in demanding environments.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult Fischer Elektronik directly for cross-reference information or equivalent products within their portfolio.
