SL 28 SMD THR 058 52 G

Headers, Male Pins Overview

The SL 28 SMD THR 058 52 G is a male pin header connector from the Fischer Elektronik SL 28 series. It features a dual-row configuration with 52 contacts arranged in two rows of 26 positions. The component utilizes a 2.54 mm (0.100 inch) pitch and a 5.08 mm row spacing layout. Designed for Surface Mount Device (SMD) and Through-Hole Reflow (THR) soldering processes, it supports automated pick-and-place assembly. The connector is rated for a nominal voltage of 250 V AC with a test voltage of 2000 V.

Headers, Male Pins Feature Summary

• Supports both surface-mount and through-hole reflow soldering techniques for versatile PCB integration
• Dual-row male header design providing high-density contact arrangements
• Precision-engineered construction ensuring reliable mechanical stability during thermal processing

Headers, Male Pins Applications

• Industrial control systems requiring robust signal interconnects
• Automotive electronics utilizing surface-mount assembly lines
• Consumer appliances needing high-density board-to-board connections

Headers, Male Pins Procurement Notes

Verify the specific part number suffix against the manufacturer's current datasheet to confirm contact plating specifications and packaging format. Ensure the ordering code matches the required 52-position configuration and dual-row layout. Cross-reference the thermal profile requirements with your assembly process capabilities to guarantee compatibility with the through-hole reflow method.

Headers, Male Pins Selection Notes

Select this component when a high-contact-count header is required for mixed mounting technologies. The dual-row layout maximizes connection density within a limited footprint. Consider the 2.54 mm pitch standard for broad compatibility with mating connectors. Evaluate the mechanical retention needs against the THR solder joint strength characteristics provided in the official documentation.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL 28 series, which specializes in compact pin headers for modern electronic assemblies. The series offers various pole counts and mounting options to suit different design constraints. The SL 28 designation indicates a specific form factor optimized for space-efficient applications while maintaining electrical reliability under standard operating conditions.

Headers, Male Pins Replacement Considerations

Consult the official Fischer Elektronik substitution guide for direct equivalents. Verify that any alternative maintains the identical 2.54 mm pitch, 52-position count, and dual-row geometry. Ensure the replacement supports the same SMD/THR mounting method and meets the required voltage ratings.
