SL 28 SMD THR 109 8 Z

Headers, Male Pins Overview

The Fischer Elektronik SL 28 SMD THR 109 8 Z is a male pin header connector designed for board-to-board and wire-to-board applications. It features an 8-position configuration with two rows, utilizing a 2.54 mm pitch spacing. The component supports both surface-mount technology (SMD) and through-hole (THR) termination methods, offering versatile mounting options. The contact length measures 10.90 mm, while the insulation height is 2.80 mm. The connector employs a push-pull fastening type and square contact shapes to ensure secure mating.

Headers, Male Pins Feature Summary

• Supports dual termination via surface-mount and through-hole soldering processes
• Utilizes a push-pull fastening mechanism for secure connection stability
• Features square contact shapes designed for reliable board-to-board interfacing

Headers, Male Pins Applications

• Board-to-board interconnections in electronic assemblies
• Wire-to-board connections requiring mixed termination support
• Precision-engineered circuits needing stable push-pull retention

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required 8-position count and dual termination capability. Confirm that the 2.54 mm pitch aligns with the target PCB footprint design. Ensure compatibility with the intended operating temperature range of -40°C to +163°C. Check that the contact plating specifications meet the environmental requirements for the application environment.

Headers, Male Pins Selection Notes

Select this component when both surface-mount and through-hole mounting flexibility is required within a single connector solution. The 2.54 mm pitch is standard for general-purpose interconnects, ensuring broad compatibility with existing PCB designs. Consider the 10.90 mm contact length for adequate mating depth in dense assembly layouts. The push-pull feature is advantageous where mechanical retention strength is critical for long-term reliability.

Headers, Male Pins Part Context

This component belongs to the Fischer Elektronik SL 28 SMD THR series, which specializes in precision pin headers. The series is engineered to provide reliable performance in surface-mount technology applications. The specific model integrates dual termination capabilities, distinguishing it from single-method connectors. This design supports diverse manufacturing workflows by accommodating different assembly techniques without compromising electrical integrity.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 8-position count, 2-row layout, and 2.54 mm pitch. Verify that alternative components support both SMD and THR termination if dual-mounting is required. Ensure the replacement maintains the 10.90 mm contact length and compatible insulation height. Cross-reference the fastening mechanism to confirm equivalent push-pull retention characteristics are present.
