SL 5 097 23 S

Headers, Male Pins Overview

The SL 5 097 23 S is a male pin header connector manufactured by Fischer Elektronik. It features a single row with 23 contacts and a 2.54 mm pitch. Designed for through-hole mounting, it utilizes selective gold plating on the contact pins to ensure reliable electrical connections. The component is part of the SL 5 series, which supports interconnections for stacked printed circuit boards.

Headers, Male Pins Feature Summary

• Single row configuration with 23 positions
• Selective gold-plated contacts for enhanced conductivity
• Through-hole mounting style for secure PCB attachment

Headers, Male Pins Applications

• Stacked PCB interconnections
• Board-to-board connections
• Wire-to-board assemblies

Headers, Male Pins Procurement Notes

Verify the specific contact length and insertion depth requirements against your PCB stack-up design. Confirm that the selective gold plating specification meets your corrosion resistance needs. Ensure the through-hole footprint matches the manufacturer's recommended land pattern for optimal solder joint integrity during assembly.

Headers, Male Pins Selection Notes

Select this model when a single-row, 23-position header is required with a standard 2.54 mm pitch. Choose the SL 5 series for applications involving stacked PCBs where selective gold plating provides necessary durability. Ensure the straight mounting orientation fits within the available vertical clearance of the enclosure.

Headers, Male Pins Part Context

This component belongs to the Fischer Elektronik SL 5 series of male pin headers. The series is characterized by its use in stacking multiple PCBs together. The 'S' designation typically indicates selective gold plating on the contact areas, distinguishing it from standard tin-plated variants within the same physical form factor.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Fischer Elektronik SL 5 series headers with matching 23 positions and 2.54 mm pitch. Verify that any alternative maintains the same through-hole mounting style and selective gold plating characteristics to ensure mechanical and electrical compatibility.
