SL 5 315 26 G

Headers, Male Pins Overview

The SL 5 315 26 G is a board connector manufactured by Fischer Elektronik, designed for reliable interconnections in complex assemblies. It features a male header configuration with 26 positions arranged in a single row. The component utilizes a 0.100-inch (2.54mm) pitch and is intended for through-hole mounting on printed circuit boards. Contacts are gold-plated to ensure durability and low contact resistance. This specific model provides a high-precision solution for electronic signal transmission.

Headers, Male Pins Feature Summary

• Gold-plated contacts for enhanced conductivity
• Through-hole mounting for secure PCB attachment
• Single-row male header design

Headers, Male Pins Applications

• Complex electronic assemblies requiring reliable interconnections
• Printed circuit board signal routing
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the exact part number against official Fischer Elektronik documentation to confirm pin count and plating specifications. Ensure compatibility with mating connectors regarding pitch and row configuration. Check for RoHS compliance status if required by project standards. Confirm availability of datasheets for detailed mechanical dimensions before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a single-row, 26-position male header with 2.54mm pitch is required. Consider the gold plating for applications demanding corrosion resistance. Evaluate the through-hole mounting style against surface-mount alternatives based on mechanical stress requirements. Compare physical dimensions against available PCB space constraints.

Headers, Male Pins Part Context

This component belongs to the Fischer Elektronik SL 5 series, which focuses on precision PCB connectors. The series offers various configurations including different pin counts and plating options. The SL 5 315 26 G represents a specific variant within this lineup, tailored for applications needing a moderate number of connections in a compact form factor.

Headers, Male Pins Replacement Considerations

Consult official Fischer Elektronik cross-reference guides for direct substitutes. Verify that any alternative maintains the same 2.54mm pitch, 26-pin count, and through-hole mounting style. Ensure mechanical fit and electrical characteristics match the original design requirements.
