SL 5 525 32 G

Headers, Male Pins Overview

The SL 5 525 32 G is a single-row male pin header connector manufactured by Fischer Elektronik. It features 32 positions with a 0.100 inch (2.54 mm) pitch, designed for through-hole mounting on printed circuit boards. The contacts are gold-plated to ensure reliable signal transmission and corrosion resistance. This component belongs to the SL 5 series, which offers selective gold plating options for specific pin lengths, making it suitable for applications requiring robust interconnections in electronic assemblies.

Headers, Male Pins Feature Summary

• Single-row male pin configuration for standard board-to-board or wire-to-board connections
• Gold-plated contacts provide enhanced conductivity and long-term reliability
• Through-hole mounting style ensures secure mechanical attachment to PCBs
• Compatible with 0.100 inch (2.54 mm) grid spacing standards

Headers, Male Pins Applications

• General-purpose electronic equipment interconnections
• Industrial control system board stacking
• Consumer electronics assembly modules
• Test and measurement instrument interfaces

Headers, Male Pins Procurement Notes

Verify that the selected part number matches the required contact count and row configuration. Confirm that the gold plating specification meets the environmental requirements of the target application. Ensure compatibility with existing PCB footprint designs before finalizing procurement orders to avoid integration issues.

Headers, Male Pins Selection Notes

Choose this connector when a single-row, through-hole male header with gold contacts is required. Consider the 32-position count and 2.54 mm pitch as primary selection criteria. Evaluate mechanical stability needs and environmental exposure levels to confirm suitability for the intended operational conditions.

Headers, Male Pins Part Context

This component is part of Fischer Elektronik's SL 5 series, which specializes in male headers with selective gold plating capabilities. The series supports various pin lengths and contact counts, catering to diverse electronic interconnection needs. Fischer Elektronik focuses on high-quality connectors for industrial and commercial applications.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 32-position count, single-row layout, 2.54 mm pitch, and through-hole mounting type. Verify that alternative components offer comparable gold-plated contact specifications and similar mechanical dimensions to ensure functional interchangeability without redesigning the host PCB.
