SL 7 13 G

Headers, Male Pins Overview

The SL 7 13 G is a male header PCB connector manufactured by Fischer Elektronik. It belongs to the SL 7 series, designed for surface mount technology applications. The component features a single row of contacts with a standard 2.54 mm pitch. It is engineered to withstand reflow soldering temperatures up to 260°C for 10 seconds, ensuring reliable performance during assembly processes.

Headers, Male Pins Feature Summary

• Low profile design suitable for space-constrained electronic assemblies
• Robust construction capable of withstanding high-temperature reflow soldering profiles
• Single row configuration providing standardized connection interfaces

Headers, Male Pins Applications

• General purpose PCB interconnections
• Industrial control modules
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the exact contact count and housing color against the specific datasheet revision. Confirm that the selected variant matches the required current rating and voltage specifications for the target application environment. Ensure compatibility with automated pick-and-place equipment if high-volume production is planned.

Headers, Male Pins Selection Notes

Select this component when a low-profile male header is required for board-to-board or cable-to-board connections. Consider the thermal resistance capabilities for lead-free soldering processes. Evaluate the mechanical stability requirements and ensure the single-row format aligns with the available PCB footprint constraints.

Headers, Male Pins Part Context

Fischer Elektronik specializes in passive electronic components, including connectors and shielding solutions. The SL 7 series represents their line of low-profile headers designed for modern surface mount manufacturing. This product line emphasizes reliability and compactness for dense circuit layouts.

Headers, Male Pins Replacement Considerations

Consult official cross-reference lists for direct substitutes. Verify pin pitch, height, and termination style before substituting with generic equivalents to maintain mechanical fit and electrical integrity.
