SL LP 5 SMD 038 17 S SM

Headers, Male Pins Overview

The SL LP 5 SMD 038 17 S SM is a surface mount pin header manufactured by Fischer Elektronik. It features 17 positions with a 2.54 mm (0.100 inch) pitch. The connector utilizes a single row configuration and is designed for board-to-board or wire-to-board applications. The contact surfaces are tin-plated, providing reliable electrical connectivity. The insulating body is constructed from PA 4.6 GF material, ensuring mechanical stability and flame resistance.

Headers, Male Pins Feature Summary

• Surface mount technology design for automated PCB assembly
• Tin-plated contacts for corrosion resistance and conductivity
• Single row header configuration with standardized spacing
• High-temperature resistant polyamide insulation

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• Industrial control systems
• Telecommunications equipment

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix 'SM' against the manufacturer's official datasheet to confirm packaging details, such as reel specifications or tape-and-reel dimensions. Ensure the part number matches the exact pin count and plating requirements for your design. Cross-reference the component code with Fischer Elektronik's current product database to confirm availability and manufacturing status before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile surface mount header is required for high-density circuit layouts. The 2.54 mm pitch ensures compatibility with standard through-hole mating connectors. Consider the thermal endurance of the PA 4.6 GF insulation for reflow soldering processes. Verify that the single-row format fits within the available PCB area constraints without interfering with adjacent components.

Headers, Male Pins Part Context

This part belongs to the SL LP 5 SMD series, which represents compact surface mount headers from Fischer Elektronik. The series is characterized by its low profile and robust construction suitable for modern electronics manufacturing. Components in this family typically offer reliable performance in demanding environments due to their material selection and plating options.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 17-position count, 2.54 mm pitch, and surface mount form factor. Verify that alternative manufacturers provide compatible tin plating and similar insulation materials like PA 4.6. Check footprint compatibility on the PCB to ensure seamless integration without redesigning the layout.
