SL LP 5 SMD 066 10 Z

Headers, Male Pins Overview

The SL LP 5 SMD 066 10 Z is a surface mount board connector from the Fischer Elektronik SL series. It features a single row of male pins with a 2.54 mm (0.100 inch) pitch and a total of 10 contacts. The housing is constructed from polyamide (PA 4.6) with glass fiber reinforcement, rated UL 94 V-0 for flammability. The tin-plated terminals ensure reliable connectivity. Designed for automated pick-and-place assembly, this low-profile component supports operating temperatures ranging from -40°C to +163°C.

Headers, Male Pins Feature Summary

• Low-profile surface mount design optimized for automated pick-and-place manufacturing processes
• High-temperature resistant polyamide insulation body ensuring stability in demanding thermal environments
• Tin-plated male contact configuration providing secure electrical connection capabilities

Headers, Male Pins Applications

• Surface mount assembly for compact electronic circuit boards
• Industrial control systems requiring high-temperature resistant interconnects
• Automated manufacturing lines utilizing pick-and-place equipment

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix 'Z' confirms tin plating rather than gold or nickel variants. Confirm the package type matches production needs, as options include bar magazines or tape and reel formats. Ensure the selected variant aligns with the required contact count and mounting style specifications for the target application.

Headers, Male Pins Selection Notes

Select this model when a low-profile, single-row header is required for surface mount technology. The 2.54 mm pitch suits standard board layouts. Consider the tin plating for cost-effective applications where gold is unnecessary. Verify that the PA 4.6 material meets the thermal and mechanical requirements of the end-use environment.

Headers, Male Pins Part Context

This component belongs to the SL LP 5 SMD series, characterized by low profile and surface mount construction. Fischer Elektronik designs these connectors for reliable performance in space-constrained electronics. The series emphasizes compatibility with automated assembly processes while maintaining robust electrical characteristics across various industrial applications.
