SL LP 7 SMD 030 34 S

Headers, Male Pins Overview

The SL LP 7 SMD 030 34 S is a surface mount connector header manufactured by Fischer Elektronik. It features a 34-position configuration with a 2.54 mm (0.100 inch) pin spacing. The component utilizes low-profile SMD technology, characterized by a compact footprint and a height of 0.635 mm. This design facilitates efficient space utilization in electronic assemblies while maintaining reliable electrical connections through precision-engineered contacts.

Headers, Male Pins Feature Summary

• Low profile surface mount construction for compact assembly
• Precision 2.54 mm pin spacing for standard compatibility
• 34-position header configuration for multi-signal routing

Headers, Male Pins Applications

• Electronic board-to-board interconnections
• Compact consumer electronics assemblies
• Industrial control module interfaces

Headers, Male Pins Procurement Notes

Verify the specific contact material and plating requirements against application environmental conditions. Confirm that the low-profile height of 0.635 mm aligns with enclosure clearance constraints. Ensure soldering profiles are compatible with surface mount reflow processes to maintain joint integrity without damaging the connector body.

Headers, Male Pins Selection Notes

Select this component when space-constrained designs require a robust 34-pin interface. The low-profile form factor is suitable for applications where vertical height is limited. Consider the mating cycle reliability and contact resistance specifications if high-frequency or high-current signals are transmitted through the header.

Headers, Male Pins Part Context

This part belongs to the SL LP 7 SMD series from Fischer Elektronik, which focuses on low-profile surface mount connectors. The series is designed for applications demanding high reliability and precise alignment in dense circuit layouts. The 34-position variant provides a balanced solution for moderate I/O density within strict spatial boundaries.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 34-position count, 2.54 mm pitch, and low-profile SMD mounting style. Verify mechanical dimensions, specifically the 0.635 mm height, to ensure fit within existing PCB footprints and enclosures. Contact material and plating should be equivalent to maintain electrical performance.
