SL LP 7 SMD 040 12 S

Headers, Male Pins Overview

The SL LP 7 SMD 040 12 S is a male header connector from the Fischer Elektronik SL LP 7 SMD series. It features a surface mount design with 12 positions and a single row configuration. The pin pitch is 2.54 mm (0.100 inches). The component operates within a temperature range of -40°C to +163°C and withstands soldering heat at 260°C for 10 seconds. The housing material meets UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Surface mount construction for automated PCB assembly
• Single row male header configuration
• High-temperature resistance up to 163°C
• UL 94 V-0 rated housing material

Headers, Male Pins Applications

• General electronic interconnections
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific part number suffix against official Fischer Elektronik documentation to confirm contact plating options and exact dimensional tolerances. Ensure compatibility with automated pick-and-place equipment specifications. Cross-reference thermal ratings with application requirements to guarantee reliability under operating conditions.

Headers, Male Pins Selection Notes

Select this component based on the requirement for a 12-position surface mount header with a 2.54 mm pitch. Consider the high-temperature rating and UL 94 V-0 compliance for robust applications. Verify that the single-row layout fits the available PCB footprint and aligns with mating connector specifications.

Headers, Male Pins Part Context

This part belongs to the SL LP 7 SMD series, which offers various position counts ranging from 6 to 29 contacts. The series provides consistent mechanical dimensions and electrical characteristics across different pole counts, allowing for modular design approaches in space-constrained surface mount applications.

Headers, Male Pins Replacement Considerations

Direct substitutes include other SL LP 7 SMD variants with matching pitch and row count, such as SL LP 7 SMD 040 8 S or SL LP 7 SMD 040 13 S, provided the position count difference is acceptable for the design.
