SL LP 7 SMD 055 28 Z

Headers, Male Pins Overview

The SL LP 7 SMD 055 28 Z is a surface mount connector header manufactured by Fischer Elektronik. It features a 2.54 mm (0.100 inch) pitch spacing and provides 28 positions for electrical connectivity. The component utilizes bronze contact material with a gold-plated surface finish to ensure reliable signal transmission. Designed for low-profile applications, it measures approximately 11 mm in length and 3.8 mm in width. The unit supports a voltage rating of 250VAC and a current rating of 3Amps, suitable for standard electronic circuit interconnections.

Headers, Male Pins Feature Summary

• Surface mount design for automated PCB assembly
• Low profile construction for space-constrained environments
• Gold-plated bronze contacts for corrosion resistance

Headers, Male Pins Applications

• Electronic circuit board interconnections
• Signal routing in compact devices
• Industrial control panel wiring

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix 'Z' against the manufacturer's official documentation to confirm plating thickness and material specifications. Ensure compatibility with mating connectors from the same series. Check thermal endurance ratings against soldering processes. Confirm package quantity details directly with authorized distributors as these are subject to change.

Headers, Male Pins Selection Notes

Select this component when a 28-position surface mount header is required. The 2.54 mm pitch is standard for many legacy and modern interfaces. Consider the low profile dimensions if vertical clearance is limited. Verify that the 3A current rating meets the application's power requirements. Ensure the operating temperature range aligns with environmental conditions.

Headers, Male Pins Part Context

This part belongs to the SL LP 7 SMD 055 series from Fischer Elektronik. The series offers various position counts ranging from 12 to 28 contacts. All variants share the same 2.54 mm pitch and surface mount footprint. The series is designed for high-density PCB layouts requiring robust mechanical stability.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Fischer Elektronik headers within the SL LP 7 SMD 055 series with identical pin counts. Cross-brand replacements require matching pitch, current rating, and mounting type. Verify mechanical dimensions before integration.
