- Description：IC PWR SWITCH N-CHAN 1:1 16STQFN
- Series：-
- Mfr：Renesas Electronics Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- Switch Type：General Purpose
- Number of Outputs：1
- Ratio - Input:Output：1:01
- Output Configuration：High Side
- Output Type：N-Channel
- Interface：-
- Voltage - Load：-
- Voltage - Supply (Vcc/Vdd)：2.5V ~ 5.5V
- Current - Output (Max)：4A
- Rds On (Typ)：15mOhm
- Input Type：CMOS
- Features：-
- Fault Protection：-
- Operating Temperature：-40°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：16-STQFN (1.6x2.5)
- Package / Case：16-PowerUFQFN
- Grade：-
- Qualification：-
Download product information
Overview
The SLG59M1714V is a power switch IC featuring four back-to-back N-channel MOSFETs designed for high-current distribution. It supports an operating supply voltage range of 2.5 V to 5.5 V and delivers a maximum output current of 4 A per channel. The device exhibits a maximum on-resistance of 20 mΩ and includes a current limit of 2 A. It operates within a temperature range of -40°C to +85°C and utilizes a 16-STQFN (1.6x2.5 mm) surface-mount package.
Feature Summary
- Integrates four independent high-side load switches with back-to-back N-channel FET architecture for robust reverse current blocking.
- Provides precise current limiting protection to safeguard downstream loads from overcurrent conditions.
- Features low on-resistance to minimize conduction losses and improve system efficiency in power distribution networks.
Applications
- High-current bus distribution in portable computing devices
- Power management units for industrial control systems
- Load switching in automotive infotainment and display subsystems
Procurement Notes
Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct packaging configuration, such as tape and reel or cut tape options. Confirm that the component meets RoHS compliance standards and check the latest production lifecycle status to guarantee long-term availability for your design implementation.
Selection Notes
Select this component when multiple isolated high-side power channels are required within a compact footprint. Ensure the application voltage does not exceed the 5.5 V maximum rating and verify that the thermal dissipation capabilities of the 16-STQFN package align with the expected continuous current load and ambient operating conditions.
Part Context
This part belongs to the SLG59 series of GreenFET load switches from Renesas Electronics. The series focuses on efficient power control with integrated protection features. The SLG59M1714V specifically addresses applications requiring multi-channel power distribution with high current handling capabilities in space-constrained environments.
Replacement Considerations
Consult the official cross-reference documentation for direct pin-compatible alternatives. Verify electrical parameters such as RDS(on) and current limits before substituting to maintain system performance integrity.
