Product Detailed Parameters
- Description：IC PWR SWITCH N-CHANNEL 1:1 8DFN
- Series：-
- Mfr：Renesas Electronics Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- Switch Type：General Purpose
- Number of Outputs：1
- Ratio - Input:Output：1:01
- Output Configuration：High Side
- Output Type：N-Channel
- Interface：-
- Voltage - Load：-
- Voltage - Supply (Vcc/Vdd)：2.5V ~ 5.5V
- Current - Output (Max)：2.5A
- Rds On (Typ)：17mOhm
- Input Type：CMOS
- Features：-
- Fault Protection：-
- Operating Temperature：-20°C ~ 70°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：8-STDFN (1x1.6)
- Package / Case：8-UFDFN
- Grade：-
- Qualification：-
Download product information
Overview
The SLG5NT1458V is a single-channel N-channel power switch manufactured by Renesas Electronics Corporation. It operates within a supply voltage range of 2.5V to 5.5V and supports a maximum continuous output current of 2.5A. The device features a typical on-resistance of 17 milliohms, ensuring efficient power delivery with minimal loss. Designed for surface-mount applications, it utilizes an 8-UFDFN package (8-STDFN 1x1.6). The component accepts CMOS logic inputs and functions as a high-side switch. It is rated for operation in ambient temperatures ranging from -20°C to 70°C.
Feature Summary
- High-efficiency power switching with low on-resistance for minimal voltage drop
- CMOS-compatible input interface for direct integration with digital control logic
- Compact surface-mount packaging optimized for space-constrained PCB layouts
Applications
- Portable electronic devices requiring efficient power management
- Battery-powered systems needing low-loss load switching
- General-purpose distribution switches in consumer electronics
Procurement Notes
Verify the specific ordering suffix against the manufacturer's official documentation to ensure correct packaging configuration. Confirm that the procurement channel provides genuine components with traceable origin. Check for any recent Product Change Notifications regarding labeling or material composition updates prior to finalizing orders.
Selection Notes
Select this component when a single-channel high-side switch is required for 3.3V or 5V systems. Ensure the load current does not exceed 2.5A and the operating environment remains within the specified temperature range. Verify that the available board space accommodates the 8-UFDFN footprint and that the driving circuitry provides compatible CMOS logic levels.
Part Context
This part belongs to the SLG5NT family of power switches from Renesas Electronics. The series focuses on providing compact, high-performance solutions for portable and battery-operated applications. These devices are designed to replace discrete MOSFET configurations, offering integrated protection and simplified design processes for modern electronic systems.
Replacement Considerations
Consult the official datasheet for pin-compatible alternatives within the SLG5NT family. Verify electrical parameters such as on-resistance and current ratings before substituting with other manufacturers' parts.
