SLV W 11 105 10 G

Headers, Male Pins Overview

The SLV W 11 105 10 G is a male pin header manufactured by Fischer Elektronik, designed for board-to-board and wire-to-board connectivity. It features a 1.27 mm pitch with 10 contacts arranged in two rows. The component utilizes through-hole straight mounting technology. Contact materials consist of copper zinc alloy with gold plating to ensure reliable electrical performance. The insulating body is constructed from PA 4.6 GF material, providing necessary mechanical stability and thermal resistance for industrial electronic applications.

Headers, Male Pins Feature Summary

• Precision-engineered male header suitable for mating with female headers
• Gold-plated contacts ensure low volume resistance and corrosion resistance
• PA 4.6 GF insulating body provides high thermal stability
• Through-hole straight design facilitates secure PCB mounting

Headers, Male Pins Applications

• Industrial electronic manufacturing systems
• Board-to-board interconnects requiring high reliability
• Wire-to-board connections in control units

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix 'G' corresponds to the required contact finish and packaging configuration. Confirm that the 10-position count matches the circuit design requirements. Ensure compatibility with the intended female header series, such as the BLM series, for proper mating engagement. Check datasheet specifications for peak reflow temperature limits to validate assembly process compatibility.

Headers, Male Pins Selection Notes

Select this component when a two-row male header with 1.27 mm pitch is required for robust industrial environments. The gold-plated contacts are essential for applications demanding low contact resistance and long-term durability. Verify that the through-hole straight form factor aligns with the PCB layout constraints. Consider the PA 4.6 GF material properties for thermal management needs during operation.

Headers, Male Pins Part Context

This part belongs to the SLV W 11 105 series of male headers from Fischer Elektronik. The series offers various position counts and configurations while maintaining consistent 1.27 mm pitch and mechanical standards. Components within this family share similar insulating body materials and contact plating options, ensuring interchangeability in design architectures where specific position counts differ.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Fischer Elektronik male headers with identical 1.27 mm pitch, two-row configuration, and gold-plated contacts. Verify that alternative parts match the 10-position count and through-hole straight mounting style. Ensure the replacement maintains the same PA 4.6 GF insulating material and current/voltage ratings for direct integration without redesign.
