SLV W 2 SMD 048 6 Z

Headers, Male Pins Overview

The SLV W 2 SMD 048 6 Z is a surface mount male header connector manufactured by Fischer Elektronik. It features a dual-row configuration with six positions arranged in a 1.27 mm x 2.54 mm pitch. The component is designed for board-to-board or wire-to-board applications, offering a rated voltage of 125VAC and a current rating of 1.5A. Constructed with glass-filled polyamide (PA46) insulation, it supports an operating temperature range from -40°C to higher limits defined by the material specifications.

Headers, Male Pins Feature Summary

• Dual-row surface mount design with wide isolation body
• High-precision construction using glass-filled polyamide insulation
• Compatible with pick-and-place pad packaging options

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• Surface mount electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Fischer Elektronik documentation to ensure correct contact count and packaging type. Confirm that the selected variant matches the required 1.27 mm x 2.54 mm pitch and dual-row configuration for your PCB layout. Check for availability of tape and reel or bar magazine packaging if automated assembly is planned.

Headers, Male Pins Selection Notes

Select this component when a low-profile, dual-row surface mount header is required for high-density layouts. Ensure the PCB footprint accommodates the 1.27 mm x 2.54 mm spacing. Consider the 1.5A current rating and 125VAC voltage limit for circuit compatibility. Verify thermal resistance requirements against the PA46 material properties.

Headers, Male Pins Part Context

This part belongs to the SLV W series of male headers from Fischer Elektronik, characterized by a 1.27 mm x 2.54 mm pitch and two-row arrangement. The series offers various contact counts, typically ranging up to 40 contacts, designed for reliable surface mounting. The 'W' designation often indicates specific body width or isolation features within the product family.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Fischer Elektronik parts within the SLV W 2 SMD 048 series with different contact counts, such as SLV W 2 SMD 048 4 Z or SLV W 2 SMD 048 16 Z, provided the pin count matches the application.
