SLV W 4 KA 036 50 G

Headers, Male Pins Overview

The SLV W 4 KA 036 50 G is a pin header connector manufactured by Fischer Elektronik. It features a 1.27 mm (0.050 inch) pitch and contains 50 contacts arranged in two rows. The component is designed for through-hole mounting with a straight orientation. It supports board-to-board and wire-to-board connections, providing a reliable interface for electronic assemblies requiring high-density interconnects.

Headers, Male Pins Feature Summary

• Two-row configuration for increased contact density within a standard footprint
• Through-hole straight termination method for secure PCB attachment
• Compatible with both board-to-board and wire-to-board application scenarios

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Wire-to-board signal routing
• General-purpose electronic assembly integration

Headers, Male Pins Procurement Notes

Verify the specific part number against official Fischer Elektronik documentation to ensure compatibility with design requirements. Confirm that the through-hole straight package style matches the printed circuit board layout. Check technical drawings for mechanical dimensions and thermal specifications before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a 1.27 mm pitch two-row header is required for through-hole applications. Ensure the 50-contact capacity aligns with the circuit design needs. Consider the straight orientation for panel or direct board stacking configurations where space constraints allow vertical insertion into the substrate.

Headers, Male Pins Part Context

This model belongs to the SLV series of pin headers from Fischer Elektronik. The series offers various contact counts and orientations to suit different connectivity demands. The SLV W 4 KA 036 50 G specifically provides a medium-density solution for standard industrial and commercial electronics requiring robust mechanical and electrical connections.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 1.27 mm pitch, 50-pin count, two-row layout, and through-hole straight termination. Verify mechanical dimensions and contact plating specifications to ensure functional equivalence without redesigning the host printed circuit board.
