SLY 10 SMD 040 42 Z

Headers, Male Pins Overview

The SLY 10 SMD 040 42 Z is a surface mount male header connector from Fischer Elektronik. It features 42 positions arranged in two rows with a 2.00 mm pitch and row spacing. The component measures 12.3 mm in length, 6.8 mm in width, and 4 mm in height. Contact plating options include gold over nickel (Ni+≥0.2µm Au) or tin over nickel (Ni+46µm Sn). It supports pick-and-place assembly via bar magazines and operates within a temperature range of -40°C to +163°C.

Headers, Male Pins Feature Summary

• Precision-engineered turned contacts suitable for signal and high-power applications
• Surface mount design compatible with automated pick-and-place processes using bar magazines
• Compact form factor optimized for dense PCB layouts

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• Signal transmission circuits
• High-power contact applications

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating type, as variants exist with different finishes such as gold or tin. Ensure the selected part matches the required number of poles and row configuration for the target PCB footprint. Confirm compatibility with automated assembly equipment specifications regarding bar magazine handling.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount male header is required for reliable board-to-board or wire-to-board connections. Consider the 2.00 mm pitch and dual-row layout for space-constrained designs. Evaluate the operating temperature range and contact material requirements against environmental conditions and current load specifications before finalizing the design.

Headers, Male Pins Part Context

This part belongs to the SLY 10 SMD series of pin headers manufactured by Fischer Elektronik. The series offers various pole counts and row configurations, all sharing a consistent 2.00 mm pitch and surface-mount architecture. These connectors are designed for precision engineering and robust electrical performance in electronic assemblies.

Headers, Male Pins Replacement Considerations

Compatible substitutes within the same series include SLY 10 SMD 040 42 G and SLY 10 SMD 040 42 S, provided the contact plating and mechanical dimensions align with the design requirements.
