SLY 11 SMD 133 4 G

Headers, Male Pins Overview

The Fischer Elektronik SLY 11 SMD 133 4 G is a surface mount header connector featuring 4 positions with a 2.54 mm pitch. It utilizes a push-pull locking mechanism and includes gold-plated contacts for reliable signal transmission. The component is designed for two-row configurations, ensuring secure mating in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Surface mount design optimized for automated assembly processes
• Push-pull locking system ensures secure connection retention
• Gold-plated contact surfaces provide corrosion resistance and stable conductivity

Headers, Male Pins Applications

• Compact consumer electronics assemblies
• Industrial control module interconnections
• Medical device circuit board connections

Headers, Male Pins Procurement Notes

Verify the specific part number against official Fischer Elektronik documentation to confirm pin count and package dimensions. Ensure compatibility with mating connectors regarding pitch and locking style. Check for RoHS compliance status if required by project specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when space constraints require a low-profile surface mount solution. The four-position configuration suits simple signal or power distribution needs. Evaluate thermal requirements against the specified operating temperature range during the design phase to ensure long-term reliability under operational loads.

Headers, Male Pins Part Context

This connector belongs to the SLY 11 series, which focuses on high-density interconnect solutions. The series offers various position counts and mounting styles to accommodate diverse PCB layout requirements. Fischer Elektronik designs these components to meet rigorous industrial standards for durability and electrical performance.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.54 mm pitch, 4-pin count, and surface mount form factor. Verify that alternative headers utilize compatible push-pull locking mechanisms to maintain mechanical integrity. Cross-reference insulation height and contact plating specifications to ensure functional equivalence.
