SLY 9 SMD 055 13 Z

$0.91

Description：0.5 MM
Series：SLY 9 SMD 055
Mfr：Fischer Elektronik
Package：Tube

SKU:2d4915b1b02f Category: Headers, Male Pins Brand: Fischer Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SLY 9 SMD 055 13 Z is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Fischer Elektronik. Its product description is 0.5 MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for SLY 9 SMD 055 13 Z

Description：0.5 MM
Series：SLY 9 SMD 055
Mfr：Fischer Elektronik
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：13
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.217" (5.50mm)
Contact Length - Post：0.130" (3.30mm)
Overall Contact Length：0.406" (10.30mm)
Insulation Height：0.059" (1.50mm)
Contact Shape：Circular
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：157.5µin (4.00µm)
Contact Finish - Post：Tin
Contact Material：Copper Tin
Insulation Material：Polyamide (PA46), Nylon 4/6, Glass Filled
Features：-
Operating Temperature：-40°C ~ 163°C
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：100VDC

Headers, Male Pins datasheet and documents for SLY 9 SMD 055 13 Z

SLY 9 SMD 055 13 Z

Headers, Male Pins Overview

The SLY 9 SMD 055 13 Z is a surface mount male pin header manufactured by Fischer Elektronik. It features a 13-position configuration with a 2.00 mm (0.079 inch) pitch. The connector utilizes a PA 4.6 GF insulating body rated for UL 94 V-0 flammability and supports a test voltage of 500 V. Operating temperatures range from -40°C to +163°C, with soldering resistance up to 260°C for 10 seconds. Plating options include Ni+Au (≥0.2µm Au), Ni+Sn, or Ni+46µm Sn.

Headers, Male Pins Feature Summary

Surface mount design compatible with pick-and-place pad and bar magazine processes
High thermal stability supporting reflow soldering at 260°C for 10 seconds
Robust insulation using PA 4.6 GF material with UL 94 V-0 classification

Headers, Male Pins Applications

Compact electronic assemblies requiring surface mount connectivity
Industrial control systems operating in extreme temperature environments
Automotive electronics utilizing high-reliability interconnects

Headers, Male Pins Procurement Notes

Verify the specific plating variant required for your application, as the base series offers Gold, Tin, or Nickel-Tin options. Confirm that the PCB footprint matches the specified SMD dimensions. Ensure the selected variant meets the necessary thermal profile for your manufacturing process. Cross-reference the exact suffix to guarantee compatibility with mating connectors.

Headers, Male Pins Selection Notes

Select this component when a 13-position surface mount header is required. Choose based on the specific plating needed for corrosion resistance or conductivity. Verify the operating temperature range against environmental conditions. Consider the mechanical height constraints of the assembly. Ensure the insulating material properties meet safety standards.

Headers, Male Pins Part Context

This part belongs to the SLY 9 SMD 055 family of compact male headers. Fischer Elektronik specializes in extruded and finger-shaped heat sinks alongside precision connectors. This series is designed for high-density applications where space is limited. The components are engineered for reliable performance in demanding industrial sectors.
