SM1-12

SM1-12 is listed in the Angle, Linear Position Measuring range at ChipApex. The manufacturer field lists TE Connectivity Measurement Specialties. Its product description is STRING POT, 7.5 INCH RANGE. Review the specifications below when checking this part for your BOM.

Angle, Linear Position Measuring specifications for SM1-12

• Description：STRING POT, 7.5 INCH RANGE
• Series：SM1
• Mfr：TE Connectivity Measurement Specialties
• Package：Box
• For Measuring：Linear Position
• Technology：-
• Rotation Angle - Electrical, Mechanical：-
• Linear Range：0 ~ 3175.00mm (0 ~ 125.00")
• Output：Resistive
• Output Signal：-
• Actuator Type：String Potentiometer
• Linearity：±0.25%
• Resistance：10 kOhms
• Resistance Tolerance：±10%
• Voltage - Supply：30V
• Mounting Type：Chassis Mount
• Termination Style：Solder Lug
• Operating Temperature：-18°C ~ 71°C
• Package / Case：Module
• Supplier Device Package：-
• Grade：-
• Qualification：-
