SMA6862MH

Overview

The SMA6862MH is a power MOSFET logic motor driver manufactured by Sanken Electric USA Inc. It features three half-bridge outputs and supports brushless DC (BLDC) motors. The device operates with a supply voltage of up to 20V and handles load voltages up to 400V maximum. It provides an output current of 1.5A per channel. The component utilizes a 24-ZIP (SMA-24) package with through-hole mounting and functions within a junction temperature range of -20°C to 150°C.

Feature Summary

• Integrates three half-bridge power MOSFET outputs for multi-phase motor control
• Compatible with standard logic interfaces for direct microcontroller connection
• Designed specifically for driving brushless DC (BLDC) motors

Applications

• Home appliance motor control systems
• Brushless DC motor drives
• Industrial automation equipment

Procurement Notes

Verify the specific suffix designation during procurement, as variations such as SMA6862MZ-LF2451 may exist. Confirm RoHS compliance status and check for end-of-life notices or active manufacturing status before finalizing orders. Ensure the selected variant matches the required packaging and lead-free specifications for your assembly process.

Selection Notes

Select this component when designing circuits requiring integrated three-phase BLDC drive capabilities in a single package. Consider the 400V load voltage rating and 1.5A output current capacity against your motor requirements. Evaluate the thermal performance within the specified -20°C to 150°C junction temperature range for your operating environment.

Part Context

This part belongs to the SMA6860 series of motor drivers from Sanken Electric. It serves as a successor or alternative to the SMA6862MZ, which has been discontinued. The series is characterized by high-voltage power MOSFET integration suitable for household appliances and industrial applications requiring reliable BLDC motor management.

Replacement Considerations

The SMA6862MZ is a confirmed substitute part number recommended by the manufacturer. Verify pinout compatibility and electrical parameters between the original design and this replacement before implementation.

FAQ

What type of motor does the SMA6862MH support?

It is designed to drive brushless DC (BLDC) motors.

What is the maximum load voltage for this driver?

The maximum load voltage rating is 400V.
