SMDA24C.TBT

SMDA24C.TBT is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Semtech Corporation. Its product description is TVS DIODE 24VWM 55VC 8-SO. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for SMDA24C.TBT

• Description：TVS DIODE 24VWM 55VC 8-SO
• Series：SMDAC
• Mfr：Semtech Corporation
• Package：Tape & Reel (TR),Cut Tape (CT)
• Type：Zener
• Bidirectional Channels：4
• Voltage - Reverse Standoff (Typ)：24V (Max)
• Voltage - Breakdown (Min)：26.7V
• Voltage - Clamping (Max) @ Ipp：55V
• Current - Peak Pulse (10/1000µs)：5A (8/20µs)
• Power - Peak Pulse：300W
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：50pF @ 1MHz
• Operating Temperature：-55°C ~ 125°C (TJ)
• Mounting Type：Surface Mount
• Package / Case：8-SOIC (0.154", 3.90mm Width)
• Supplier Device Package：8-SO
• Unidirectional Channels：-
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for SMDA24C.TBT
