SML-LXIL0603SIC-TR

LED Indication - Discrete Overview

The SML-LXIL0603SIC-TR is a single-color surface-mount LED manufactured by Lumex Opto/Components Inc. It features a red lens with a water-clear finish and emits light at a peak wavelength of 636 nm. The component operates with a forward current of 20 mA and a typical forward voltage of 2 V, resulting in a power rating of 105 mW. It provides an optical intensity of 70 mcd within a 0603 (1608 metric) package measuring 1.6 mm in length and 0.8 mm in width. The device complies with RoHS3 standards.

LED Indication - Discrete Feature Summary

• Utilizes a rectangular lens design with a water-clear transparency for efficient light transmission.
• Engineered for surface-mount technology (SMD/SMT) installation to facilitate automated assembly processes.
• Constructed with a colorless lens material to maintain spectral purity of the emitted red light.

LED Indication - Discrete Applications

• Status indication in electronic circuits
• Panel indicator lights
• Consumer electronics signaling

LED Indication - Discrete Procurement Notes

Verify the specific suffix 'SIC' against the manufacturer's official documentation to confirm the exact lens color and optical characteristics, as variations exist within the series. Ensure compatibility with standard reflow soldering profiles for 0603 packages. Confirm moisture sensitivity level requirements prior to storage and handling to prevent damage during assembly.

LED Indication - Discrete Selection Notes

Select this component when a compact red indicator is required for space-constrained designs. The 0603 footprint offers a balance between visibility and board area efficiency. Consider the 70 mcd intensity for general status applications where high brightness is not critical. Verify that the 2 V forward voltage aligns with the driving circuit's output capabilities.

LED Indication - Discrete Part Context

This part belongs to the Lumex SML-LXIL0603 series, which focuses on compact narrow-beam LEDs. The series is known for its established quality record and suitability for modern surface-mount manufacturing. The SML-LXIL0603SIC-TR specifically addresses the need for reliable red indicators in small form-factor devices.

LED Indication - Discrete Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Cross-referencing requires consulting the manufacturer's official replacement guide or datasheet for equivalent electrical and mechanical specifications.
