SMS12RE4S6

Headers, Male Pins Overview

The Souriau-Sunbank by Eaton SMS12RE4S6 is a four-row connector housing designed for high-density applications. It features twelve contacts with a 5.08 mm pitch and utilizes a locking ramp fastening mechanism. Constructed from black copper alloy and insulation, this component supports robust electrical connections in demanding environments.

Headers, Male Pins Feature Summary

• Four-row configuration for increased contact density
• Locking ramp fastening mechanism for secure engagement
• Copper alloy contact material for reliable conductivity

Headers, Male Pins Applications

• Industrial control systems requiring high-density interconnects
• Automotive electronics harnesses
• Aerospace wiring assemblies

Headers, Male Pins Procurement Notes

Verify the specific locking ramp mechanism compatibility with mating connectors. Confirm insulation color and material specifications against project requirements. Ensure the four-row layout aligns with panel or cable assembly constraints before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this housing when a compact, four-row arrangement is necessary to maximize contact count within limited space. The locking ramp feature provides enhanced retention compared to standard snap-fit designs. Evaluate the 5.08 mm pitch against existing board or cable spacing requirements.

Headers, Male Pins Part Context

This part belongs to the SMS series of heavy-duty connectors. The series is known for modular design options allowing various row counts and contact configurations. The SMS12RE4S6 specifically addresses needs for multi-row connectivity in industrial settings.

Headers, Male Pins Replacement Considerations

Check for direct cross-references within the Souriau-Sunbank by Eaton catalog. Verify mechanical dimensions and locking interface compatibility with existing mating components before substituting.
