Product Detailed Parameters
- Description：NMC 100.0UH 5.0A 0.0400 OHM TH
- Series：SN
- Mfr：KEMET
- Package：Tray
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：-
- DC Resistance (DCR) (Max)：-
- Voltage Rating - DC：-
- Voltage Rating - AC：-
- Operating Temperature：-25°C ~ 105°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：-
- Height (Max)：-
- Package / Case：Vertical, No Base, 2 PC Pin
- Inductance @ Frequency：100 µH @ 100 kHz
- Qualification：-
- Grade：-
Download product information
Overview
The KEMET SN12P-500 is a vertical through-hole common mode choke designed for AC line filtering applications. It features an inductance of 100 µH at 100 kHz and supports a maximum DC current rating of 5 A. The component exhibits a maximum DC resistance of 40 mΩ (0.04 Ω). It operates within a temperature range from -40°C to +105°C. The package utilizes two PC pins with no base, suitable for standard PCB mounting.
Feature Summary
- Provides effective common mode noise suppression for AC power lines
- Supports high current handling up to 5 Amperes
- Vertical through-hole construction for robust mechanical stability
Applications
- AC power input filtering
- Switch-mode power supply EMI reduction
- General electronic equipment noise suppression
Procurement Notes
Verify the specific part number suffix against official KEMET documentation to ensure correct electrical ratings and physical dimensions. Confirm that the 5A current rating and 100µH inductance align with your circuit requirements. Check for any specific packaging or reel options if available in official datasheets. Ensure compatibility with your assembly process regarding through-hole mounting constraints.
Selection Notes
Select this component when designing circuits requiring common mode chokes with a 100µH inductance and 5A current capacity. Consider the vertical package profile and pin spacing for PCB layout. Evaluate thermal management needs given the 105°C maximum operating temperature. Compare DCR specifications against efficiency requirements for power stages.
Part Context
This component belongs to the KEMET SN series of common mode chokes. These components are engineered for electromagnetic interference suppression in power electronics. The SN series typically offers various inductance and current ratings to suit different power levels and noise environments.
Replacement Considerations
Consult official KEMET substitution guides for verified equivalents. Cross-reference inductance, current rating, and physical dimensions before substituting.
