SN65LVCP114ZJA

$22.67

Description：IC MULTIPLEXER 4CH 167NFBGA
Series：-

SKU:0754b35a4ed4 Category: Signal Buffers, Repeaters, Splitters Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC MULTIPLEXER 4CH 167NFBGA
Series：-
Mfr：Texas Instruments
Package：Tray
Type：Buffer, Multiplexer
Applications：-
Input：CML
Output：CML
Data Rate (Max)：14.2Gbps
Number of Channels：4 x 2:1, 1:2
Delay Time：200ps
Signal Conditioning：Input Equalization, Output Pre-Emphasis
Voltage - Supply：2.375V ~ 3.465V
Current - Supply：-
Operating Temperature：-40°C ~ 85°C
Mounting Type：Surface Mount
Package / Case：167-LFBGA
Supplier Device Package：167-NFBGA (12x12)
Capacitance - Input：-
Grade：-
Qualification：-

Download product information

SN65LVCP114ZJA

Overview

The SN65LVCP114ZJA is a high-speed interface component manufactured by Texas Instruments, housed in a 38-pin VQFN package. It integrates four independent channels of multiplexing and linear redriving capabilities within a single device. The circuit supports data rates up to 14.2 Gbps, enabling efficient signal conditioning for demanding digital applications. Designed for surface-mount installation, it operates across a commercial temperature range from 0°C to 85°C. The unit functions as a quad 1:2/2:1 mux with integrated signal conditioning features.

Feature Summary

Integrates four independent channels combining 1:2 and 2:1 multiplexing with linear redriving functionality
Provides advanced signal conditioning capabilities to maintain signal integrity at high speeds
Supports data transmission rates reaching up to 14.2 Gbps per channel

Applications

High-speed serial link interconnects requiring signal regeneration
Data center infrastructure equipment
Telecommunications networking hardware

Procurement Notes

Verify the specific suffix ZJA confirms the VQFN-38 package configuration during sourcing. Confirm RoHS compliance status through official manufacturer documentation before integration. Ensure ESD handling protocols are followed due to the sensitive nature of high-speed semiconductor components.

Selection Notes

Select this component when four independent lanes require combined muxing and redriving in a compact form factor. The 14.2 Gbps capability suits applications exceeding standard Gigabit Ethernet requirements. Evaluate thermal dissipation needs for the VQFN-38 package under continuous high-speed operation conditions.

Part Context

This part belongs to the SN65LVCP series of high-speed interface ICs from Texas Instruments. The series focuses on providing flexible signal routing and conditioning solutions for modern digital communication systems. It serves as a specialized solution for managing complex signal paths in high-bandwidth environments.
