SN74AUP1G32YEPR

Overview

The SN74AUP1G32YEPR is a low-power single 2-input positive-OR gate from the Texas Instruments SN74AUP1Gxx series. It operates within a supply voltage range of 0.8 V to 3.6 V and supports an output drive current of 4 mA at both high and low logic states. The device features a static current of 500 nA and functions reliably across an operating temperature range of -40°C to +85°C. It is housed in a DSBGA-5 package.

Feature Summary

• Single-channel 2-input OR logic function
• Low power consumption with 500 nA static current
• Wide supply voltage operation from 0.8 V to 3.6 V
• Robust 4 mA output drive capability

Applications

• Portable battery-powered equipment
• Consumer electronics
• Handheld devices
• Wireless communications

Procurement Notes

Verify the specific suffix YEPR against the official datasheet to confirm the DSBGA-5 package type and tape-and-reel delivery format. Ensure the component meets RoHS compliance requirements for your assembly process. Cross-reference the manufacturer part number with authorized distributors to avoid counterfeit components.

Selection Notes

Select this component when a compact, low-voltage OR gate is required for space-constrained designs. The wide input voltage range facilitates interfacing with various logic families. Consider the DSBGA-5 footprint for surface-mount applications requiring minimal board area.

Part Context

This device belongs to the SN74AUP1Gxx family of ultra-low-power single-gate logic ICs. These components are designed for portable applications where energy efficiency and small form factors are critical. The AUP series offers performance comparable to standard CMOS while significantly reducing power dissipation.

Replacement Considerations

SN74AUP1G32DCKR
