Product Detailed Parameters
- Description：IC GATE OR 2CH 2-INP 8DSBGA
- Series：74AUP
- Mfr：Texas Instruments
- Package：Tape & Reel (TR),Cut Tape (CT)
- Logic Type：OR Gate
- Number of Circuits：2
- Number of Inputs：2
- Features：-
- Voltage - Supply：0.8V ~ 3.6V
- Current - Quiescent (Max)：500 nA
- Current - Output High, Low：4mA, 4mA
- Input Logic Level - Low：0.7V ~ 0.9V
- Input Logic Level - High：1.6V ~ 2V
- Max Propagation Delay @ V, Max CL：6.2ns @ 3.3V, 30pF
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：Surface Mount
- Supplier Device Package：8-DSBGA
- Package / Case：8-XFBGA, DSBGA
- Grade：-
- Qualification：-
Download product information
Overview
The SN74AUP2G32YFPR is a dual-channel, low-power Schmitt-trigger buffer manufactured by Texas Instruments. It operates within a supply voltage range of 0.8V to 3.6V and features two independent input lines with corresponding outputs. The device utilizes a DSBGA-8 package and supports surface-mount installation. It provides a low-level output current of 4mA and maintains static current at 500nA. The operational temperature range spans from -40°C to +85°C.
Feature Summary
- Dual-channel configuration for independent signal buffering
- Low power consumption suitable for battery-operated applications
- Schmitt-trigger inputs for noise immunity
Applications
- Signal buffering in portable electronic devices
- Level shifting between different logic families
- Noise filtering in communication interfaces
Procurement Notes
Verify the specific suffix YFPR against the official Texas Instruments datasheet to confirm the DSBGA-8 package type and tape-and-reel packaging details. Ensure compatibility with the target PCB footprint and reflow soldering profile requirements specified in the manufacturer's guidelines before finalizing procurement orders.
Selection Notes
Select this component when dual-channel buffering with Schmitt-trigger functionality is required in space-constrained designs. The AUP series offers superior speed-to-power efficiency compared to older logic families. Confirm that the 0.8V minimum operating voltage aligns with the system's power rail capabilities and that the 4mA drive strength meets load requirements.
Part Context
This part belongs to the SN74AUP2Gxx family of ultra-low-power logic ICs from Texas Instruments. The AUP series is designed for high-speed, low-voltage applications where power efficiency is critical. The '2G' designation indicates a dual-gate configuration within a compact package, distinguishing it from single-gate or quad-gate variants in the same logical family.
FAQ
What is the logic function of the SN74AUP2G32YFPR?
It functions as a dual 2-input OR gate.
Does this component include Schmitt-trigger inputs?
Yes, the SN74AUP2G32YFPR features Schmitt-trigger inputs to improve noise immunity.
