SN74LVC1G08DPWR

Inverter Gates Overview

The SN74LVC1G08DPWR is a single 2-input positive-AND gate from Texas Instruments' LVC logic family. It operates within a supply voltage range of 1.65V to 3.6V, with typical operation at 1.8V, 2.5V, 3.3V, and 5V. The device features push-pull outputs capable of ±32mA drive current. Propagation delay is specified as 4.5ns at 3.3V and 4ns at 5V under maximum capacitive load. It utilizes CMOS process technology and is housed in a 4-pin X2SON package with an exposed pad.

Inverter Gates Feature Summary

• Single-channel architecture containing one independent 2-input AND logic function
• CMOS construction enabling low static power consumption
• Push-pull output stage providing defined high and low states

Inverter Gates Applications

• Automotive electronic systems requiring compliant logic components
• Portable consumer electronics utilizing low-voltage power supplies
• Embedded computing modules requiring compact surface-mount integration

Inverter Gates Procurement Notes

Verify the specific suffix DPWR against official Texas Instruments documentation to confirm the X2SON package type and tape-and-reel shipping configuration. Ensure the component status remains active for production use. Cross-reference RoHS compliance and automotive qualification requirements with the manufacturer's latest datasheet before finalizing procurement specifications.

Inverter Gates Selection Notes

Select this component when a single 2-input AND function is required in space-constrained designs. The LVC series offers compatibility with standard logic levels while supporting lower supply voltages. The X2SON package provides a small footprint suitable for dense PCB layouts. Verify that the propagation delay and output drive capabilities meet the specific circuit timing and load requirements.

Inverter Gates Part Context

This part belongs to the SN74LVC1Gxx series of single-function gates manufactured by Texas Instruments. The LVC family is designed for low-voltage applications, bridging the gap between older 5V logic and modern low-power standards. The SN74LVC1G08 specifically implements the AND logic function, distinguishing it from other variants like NAND or NOR gates within the same package lineup.

Inverter Gates Replacement Considerations

Check for SN74LVC1G08DCKR or SN74LVC1G08DBVR if alternative packaging such as SC-70 or SOT-23 is required. Ensure any substitute maintains the same LVC logic family characteristics and voltage operating ranges.
