SN8S-500JB

$3.22

Description：CMC 72UH 2A 2LN TH
Series：SN
Mfr：KEMET
Package：Bulk

SKU:fe0f7c2ae575 Category: Common Mode Chokes Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 72UH 2A 2LN TH
Series：SN
Mfr：KEMET
Package：Bulk
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：2A
DC Resistance (DCR) (Max)：85mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-25°C ~ 105°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.709" L x 0.492" W (18.00mm x 12.50mm)
Height (Max)：0.854" (21.70mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：72 µH @ 100 kHz
Qualification：-
Grade：-

Download product information

SN8S-500JB

Overview

The KEMET SN8S-500JB is a single-channel common mode choke from the SN-JB series, designed for through-hole PCB mounting. It features a ferrite core and provides an inductance of 72 µH at 100 kHz. The component supports a maximum DC current of 2 A with a maximum DC resistance of 85 mΩ. It operates within a temperature range of -25°C to +105°C and is rated for 250 VAC.

Feature Summary

Single-channel common mode filtering capability
Through-hole termination style for PCB integration
Ferrite core construction for noise suppression

Applications

Power supply line filtering
Electromagnetic interference suppression in electronic circuits

Procurement Notes

Verify the specific part number suffix against official KEMET documentation to ensure correct electrical characteristics. Confirm that the required inductance and current ratings align with the design specifications before procurement. Check for RoHS compliance status as indicated in the manufacturer's datasheet.

Selection Notes

Select this component when a single-line common mode choke with 72 µH inductance is required. Ensure the application environment stays within the -25°C to +105°C operating temperature range. Verify that the 2 A current rating meets the circuit's maximum DC current requirements.

Part Context

This component belongs to the SN-JB series of radial leaded common mode chokes manufactured by KEMET. These components are engineered for general-purpose electromagnetic interference filtering in power applications, offering a balance of performance and cost-effectiveness for standard PCB designs.

Replacement Considerations

Cross-reference with other SN-JB series variants if different inductance values are needed. Ensure any substitute maintains the same through-hole footprint and voltage rating.
