SN8S-50P2

Overview

The KEMET SN8S-50P2 is a through-hole common mode choke filter designed for AC line filtering applications. It features an inductance of 72 µH and supports a maximum DC current of 2 A. The component has a maximum DC resistance of 75 mΩ and operates within a temperature range of -25°C to +105°C. It utilizes a toroidal core construction and is packaged in trays.

Feature Summary

• Provides common mode noise suppression for power lines
• Utilizes a toroidal iron core for efficient magnetic coupling
• Designed for through-hole PCB mounting

Applications

• AC power line filtering
• Power supply input stages
• EMI suppression in electronic equipment

Procurement Notes

Verify the specific datasheet version to confirm exact electrical tolerances and mechanical dimensions. Ensure the procurement channel provides original manufacturer documentation. Check for RoHS compliance status as indicated in the official specification sheet before finalizing orders.

Selection Notes

Select this component when a 72 µH inductance at 2 A is required for common mode noise reduction. Consider the through-hole package style and operating temperature range of -25°C to +105°C. Evaluate the 75 mΩ DC resistance against circuit efficiency requirements.

Part Context

This part belongs to the KEMET SN series of common mode chokes. These components are engineered for general-purpose power line filtering. The SN8S-50P2 variant specifically offers 72 µH inductance with a 2 A current rating, suitable for standard AC mains applications.

Replacement Considerations

Check for direct substitutes with identical 72 µH inductance and 2 A current rating. Verify pin compatibility and physical dimensions for through-hole mounting. Ensure equivalent DC resistance and temperature performance characteristics match the original design requirements.
