SP105-222K

Fixed Inductors Overview

The CODACA SP105-222K is a fixed power inductor featuring an unshielded drum core and wirewound construction. It provides an inductance of 2200 µH with a maximum DC resistance of 4.536 Ohms. The component supports a current rating of 360 mA and utilizes a 2-SMD surface mount package. Designed for robust performance, it operates within a temperature range of -40°C to +125°C, including coil temperature variations.

Fixed Inductors Feature Summary

• Unshielded drum core design for specific magnetic field requirements
• Wirewound construction ensuring stable inductance characteristics
• Surface mount packaging facilitating automated assembly processes

Fixed Inductors Applications

• Buck converter circuits
• Laptop power management systems
• Network communication equipment

Fixed Inductors Procurement Notes

Verify the exact part number against official manufacturer documentation to ensure compatibility with circuit requirements. Confirm that the specified current rating and inductance values align with the target application's electrical specifications before procurement.

Fixed Inductors Selection Notes

Select this component based on its specific inductance value and current handling capabilities required for the power stage. Ensure the physical dimensions of the 2-SMD package fit the available PCB space and consider the operating temperature range for thermal management.

Fixed Inductors Part Context

This component belongs to the SP105 series of SMD power inductors manufactured by CODACA Electronic. The series is designed for high-current applications and includes various inductance options to suit different power conversion needs across consumer electronics and industrial equipment.

Fixed Inductors Replacement Considerations

Consult official substitution lists from CODACA or authorized distributors for verified equivalent parts. Ensure any replacement matches the inductance, current rating, and physical footprint specifications.
