SP2027M00020T1521003

Crystals Overview

The SP2027M00020T1521003 is a 27 MHz quartz crystal resonator manufactured by Hefei Jingweite Electronics Co., Ltd. It features a frequency tolerance of ±10ppm and operates with a load capacitance of 20pF. The component exhibits an equivalent series resistance (ESR) of 20 Ohms and provides frequency stability of ±30ppm. Designed for surface-mount or through-hole integration, it utilizes the HC-49/U package format to ensure reliable oscillation in timing circuits.

Crystals Feature Summary

• Provides precise 27 MHz frequency generation for clock signals
• Ensures stable operation within specified temperature ranges
• Compatible with standard oscillator circuit designs

Crystals Applications

• Real-time clock circuits
• Microcontroller system clocks
• Communication equipment timing

Crystals Procurement Notes

Verify that the supplier provides official documentation confirming the ±10ppm tolerance and 20pF load capacitance specifications. Ensure the HC-49/U package dimensions match your PCB footprint requirements. Request batch testing reports to confirm ESR values remain at or below 20 Ohms for consistent performance in your specific application environment.

Crystals Selection Notes

Select this component when a fixed 27 MHz reference is required for synchronous data transmission or timing control. The low ESR specification supports efficient energy transfer in standard parallel resonance modes. Consider the ±30ppm stability rating against your system's jitter budget and phase noise requirements before finalizing the design.

Crystals Part Context

Hefei Jingweite Electronics Co., Ltd. specializes in the research and production of high-quality quartz crystals. This model belongs to their standard crystal resonator lineup, designed for industrial and consumer electronics applications requiring reliable frequency control without active oscillator components.

Crystals Replacement Considerations

Cross-reference with other 27 MHz HC-49/U crystals from manufacturers such as NDK or ECS. Verify that substitute parts maintain identical 20pF load capacitance and ≤20 Ohm ESR to ensure circuit compatibility without redesigning the oscillator network.

Crystals FAQ

What is the maximum operating temperature range?

Specific temperature limits are not provided in the available public documentation; consult the manufacturer datasheet for environmental ratings.

Is this component suitable for automotive applications?

Public data does not specify AEC-Q200 qualification or automotive-grade reliability standards for this specific part number.
