SP385ACA-L/TR

Drivers, Receivers, Transceivers Overview

The SP385ACA-L/TR is a micropower two-terminal band-gap voltage reference manufactured by Sipex. It provides a stable output voltage with high stability derived from low temperature coefficient thin film resistor processes and laser trimming at the wafer level. The device supports a wide operating current range from 10uA to 20mA, making it suitable for precision applications requiring minimal power consumption.

Drivers, Receivers, Transceivers Feature Summary

• Micropower two-terminal band-gap design
• High stability via thin film resistor process
• Laser trimmed at wafer level

Drivers, Receivers, Transceivers Applications

• Micropower voltage references
• Precision measurement circuits
• Battery-powered instrumentation

Drivers, Receivers, Transceivers Procurement Notes

Verify the manufacturer designation as Sipex or its successor entities like MaxLinear/Exar due to corporate acquisitions. Confirm the specific suffix 'ACA' corresponds to the intended package and temperature grade in official documentation before procurement.

Drivers, Receivers, Transceivers Selection Notes

Select this component when a fixed voltage reference with ultra-low quiescent current is required. Ensure the application operates within the specified 10uA to 20mA current range to maintain regulation accuracy and stability.

Drivers, Receivers, Transceivers Part Context

This part belongs to the SP385 series of voltage references. It is functionally similar to other micropower band-gap references but is distinguished by its specific manufacturing process and laser trimming characteristics provided by Sipex.
