SPC5607BAVLU6

Microcontrollers Overview

The SPC5607BAVLU6 is a 32-bit microcontroller from the MPC560xB series, manufactured by NXP Semiconductors. It features an e200z0h core with a maximum clock frequency of 64 MHz. The device includes 1 MB of Flash program memory and 48 kB of data RAM. It offers 133 I/O pins and supports multiple communication interfaces including CAN, SPI, and SCI. The ADC resolution is configurable at 10-bit or 12-bit. Operating voltage ranges from 3 V to 5.5 V, with an operating temperature range of -40°C to +105°C. It is housed in an LQFP-176 package and holds AEC-Q100 qualification.

Microcontrollers Feature Summary

• Integrated automotive-grade reliability with AEC-Q100 certification for harsh environment operation.
• Supports AUTOSAR software architecture for standardized embedded development.
• Includes Memory Protection Unit (MPU) for enhanced system security.
• Features multiple high-speed communication peripherals for complex network topologies.

Microcontrollers Applications

• Automotive body electronics control modules
• Industrial control systems requiring robust real-time processing
• Sensor fusion applications in advanced driver assistance systems

Microcontrollers Procurement Notes

Verify the specific ordering suffix against the official NXP datasheet to ensure correct pinout, memory configuration, and temperature grade. Confirm package type compatibility during PCB design. Check for moisture sensitivity levels and reflow soldering profile requirements prior to assembly. Ensure supply chain authenticity through authorized distributors.

Microcontrollers Selection Notes

Select this component when a balance of moderate flash capacity and high I/O count is required for body control applications. Compare against other MPC560xB variants if higher clock speeds or different memory sizes are needed. Consider the e200z0h core performance relative to power consumption constraints. Verify peripheral availability matches specific interface requirements such as LINFlex or additional CAN channels.

Microcontrollers Part Context

This part belongs to the MPC560xB family, designed for cost-sensitive automotive and industrial applications. It shares architectural similarities with the MPC560xP and MPC560xC series but differs in memory size and peripheral integration. The family emphasizes long-term availability and functional safety compliance for critical vehicle subsystems.

Microcontrollers Replacement Considerations

Direct substitutes within the same package and pinout include other MPC5607B variants with matching memory configurations. Cross-reference with MPC5606B or MPC5605B series parts only if reduced memory or I/O counts are acceptable. Verify software compatibility before swapping between different memory densities in the same family.
