SPC5643AF0MVZ1 is listed in the Microcontrollers range at ChipApex. The manufacturer field lists NXP USA Inc.. Its product description is IC MCU 32BIT 3MB FLASH 324PBGA. Review the specifications below when checking this part for your BOM.
Microcontrollers specifications for SPC5643AF0MVZ1
- Description：IC MCU 32BIT 3MB FLASH 324PBGA
- Series：MPC56xx Qorivva
- Mfr：NXP USA Inc.
- Package：Tray
- Core Processor：e200z4
- Core Size：32-Bit Single-Core
- Speed：150MHz
- Connectivity：CANbus, EBI/EMI, LINbus, SCI, SPI
- Peripherals：DMA, POR, PWM, WDT
- Number of I/O：151
- Program Memory Size：3MB (3M x 8)
- Program Memory Type：FLASH
- EEPROM Size：-
- RAM Size：192K x 8
- Voltage - Supply (Vcc/Vdd)：1.14V ~ 5.25V
- Data Converters：A/D 40x12b
- Oscillator Type：Internal
- Operating Temperature：-40°C ~ 125°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：324-PBGA (23x23)
- Package / Case：324-BBGA
Microcontrollers datasheet and documents for SPC5643AF0MVZ1
Microcontrollers Overview
The SPC5643AF0MVZ1 is a 32-bit microcontroller from the MPC56xx Qorivva series, featuring an e200z4 Power Architecture core. It integrates 3MB of flash memory and operates at clock frequencies up to 150MHz. The device is housed in a 324-BGA package with surface mount mounting type. Designed for automotive applications, it supports a wide operating temperature range and includes safety features compliant with ASIL standards.
Microcontrollers Feature Summary
- High-performance 32-bit processing capability using the e200z4 core architecture
- Large integrated non-volatile memory storage for complex application code
- Automotive-grade reliability designed for safety-critical powertrain environments
Microcontrollers Applications
- Safety-critical powertrain control systems
- Engine management units
- Transmission control modules
Microcontrollers Procurement Notes
Verify the specific suffix MVZ1 corresponds to the 324-BGA package and 150MHz speed grade when sourcing. Confirm that the component meets the required Automotive Safety Integrity Level (ASIL) certification for your specific application context. Ensure compatibility with existing board layouts due to the BGA footprint requirements.
Microcontrollers Selection Notes
Select this model when high code capacity is required alongside robust automotive safety compliance. The e200z4 core offers a balance of performance and deterministic execution suitable for real-time control loops. Consider the physical constraints of the 324-BGA package during PCB design and assembly planning.
Microcontrollers Part Context
This part belongs to the ultra-reliable MPC56xx family, which targets automotive and industrial control markets. It shares architectural similarities with other MPC564x variants but distinguishes itself through higher flash density and specific packaging options tailored for high-pin-count peripheral integration.
Microcontrollers Replacement Considerations
Check for direct substitutes within the MPC564xA series that offer compatible pinouts and software interfaces. Verify if lower or higher frequency variants provide sufficient performance margins while maintaining package compatibility.
