SPCT 62/22 30/5 A VA 1 CL 5-CU-ROHS

Overview

The SPCT 62/22 30/5 A VA 1 CL 5-CU-ROHS is a non-invasive solid core current transformer manufactured by Selec Controls USA Inc. It features a bus bar design with an inner dimension of 62x22 mm, accommodating conductors up to 30A primary current. The device provides a 5A secondary output with a 30:5 ratio. Rated for 50Hz to 60Hz operation, it offers Class 5 accuracy at a maximum burden of 1VA. The unit supports DIN rail mounting and complies with RoHS standards.

Feature Summary

• Non-invasive solid core construction for safe current sensing
• Bus bar format designed for direct conductor passage
• Class 5 accuracy rating ensures reliable measurement performance
• RoHS compliant manufacturing process

Applications

• Electrical panel metering systems
• Industrial power monitoring circuits
• Energy management instrumentation

Procurement Notes

Verify the specific accuracy class requirement matches your application needs, as this unit is rated Class 5. Confirm that the primary current does not exceed 30A and the burden remains within 1VA limits. Ensure physical clearance accommodates the 62x22mm aperture. Check for RoHS compliance documentation if required by project specifications.

Selection Notes

Select this model when a 30A primary current range is required with a standard 5A secondary output. The 62x22mm aperture suits rectangular or flat bus bars. Consider the Class 5 accuracy sufficient for general indication rather than precise billing. Verify DIN rail compatibility if space-constrained mounting is necessary.

Part Context

This component belongs to the SPCT series of current transformers from Selec Controls. The series includes various ratios and aperture sizes, such as the SPCT 62/40 and SPCT 50/30 models. These units are designed for industrial applications requiring isolated current measurement without breaking the circuit.

Replacement Considerations

Direct substitutes must match the 30/5A ratio, 62x22mm aperture, and Class 5 accuracy. Generic replacements may differ in burden capacity or mounting style. Verify electrical isolation ratings and frequency response (50/60Hz) before substitution.
