SPM6530T-4R7M-HZ

$1.33

Description：FIXED IND 4.7UH 5.6A 39.38 MOHM
Series：SPM-HZ
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e76faf8115c6 Category: Fixed Inductors Brand: TDK Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SPM6530T-4R7M-HZ is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists TDK Corporation. Its product description is FIXED IND 4.7UH 5.6A 39.38 MOHM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for SPM6530T-4R7M-HZ

Description：FIXED IND 4.7UH 5.6A 39.38 MOHM
Series：SPM-HZ
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Metal
Inductance：4.7 µH
Tolerance：±20%
Current Rating (Amps)：5.6 A
Current - Saturation (Isat)：4.6A
Shielding：Shielded
DC Resistance (DCR)：39.38mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.280" L x 0.256" W (7.10mm x 6.50mm)
Height - Seated (Max)：0.118" (3.00mm)
Features：-

Fixed Inductors datasheet and documents for SPM6530T-4R7M-HZ

SPM6530T-4R7M-HZ

Fixed Inductors Overview

The TDK SPM6530T-4R7M-HZ is a shielded surface-mount power inductor with a nominal inductance of 4.7 µH and a tolerance of ±20%. It features a maximum DC resistance of 39.4 mΩ, a saturation current of 6.2 A, and a rated current of 5.6 A. The component measures 7.1 mm x 6.5 mm x 3.0 mm and operates within a temperature range of -40°C to +125°C. It meets the AEC-Q200 automotive qualification standard.

Fixed Inductors Feature Summary

Shielded drum core construction minimizes electromagnetic interference
AEC-Q200 qualified for automotive reliability requirements
High saturation and rated current capabilities for power management

Fixed Inductors Applications

Automotive electronic systems
On-board charger circuits
DC/DC converter modules

Fixed Inductors Procurement Notes

Verify the specific suffix HZ against the official TDK datasheet to confirm automotive grade status and exact electrical parameters. Ensure the ordering part number matches the required inductance value and current ratings for the target application circuit design.

Fixed Inductors Selection Notes

Select this component when high current handling and low DCR are critical for efficiency. The shielded design supports dense PCB layouts by reducing magnetic coupling. Verify thermal performance under continuous load conditions within the specified operating temperature range.

Fixed Inductors Part Context

This model belongs to the TDK SPM series of shielded power inductors. It utilizes a metal powder core and is designed for surface mount technology. The series provides robust performance for demanding power supply applications requiring compact form factors.
