SPQ105-181M

$0.63

Description：SMD POWER INDUCTOR
Series：SPQ105
Mfr：CODACA
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:bd8a230ba000 Category: Fixed Inductors Brand: CODACA

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SPQ105-181M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists CODACA. Its product description is SMD POWER INDUCTOR. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for SPQ105-181M

Description：SMD POWER INDUCTOR
Series：SPQ105
Mfr：CODACA
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Wirewound
Material - Core：Ferrite
Inductance：180 µH
Tolerance：±20%
Current Rating (Amps)：1.16 A
Current - Saturation (Isat)：1.1A
Shielding：Shielded
DC Resistance (DCR)：406mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：-
Mounting Type：Surface Mount
Package / Case：2-SMD
Supplier Device Package：105
Size / Dimension：-
Height - Seated (Max)：0.189" (4.80mm)
Features：-

Fixed Inductors datasheet and documents for SPQ105-181M

SPQ105-181M

Fixed Inductors Overview

The CODACA SPQ105-181M is a shielded, drum core, wire-wound surface-mount power inductor. It features an inductance of 180 µH with a tolerance of ±20%. The component has a maximum DC resistance (DCR) of 406 mΩ and a rated current of 1.16 A. Saturation current (Isat) is specified at 1.10 A. The package dimensions are 12.00mm x 12.00mm x 7.80mm max. It operates within a temperature range of -40°C to 125°C and is tested at 100 kHz.

Fixed Inductors Feature Summary

Magnetic shielded structure for reduced electromagnetic interference
Low DCR design supporting high rated current applications
RoHS compliant lead-free product suitable for SMT processes

Fixed Inductors Applications

Power supply circuits requiring compact shielding
SMT assembly lines utilizing carrier tape packing
High-current low-noise electronic systems

Fixed Inductors Procurement Notes

Verify the specific manufacturer part number against official datasheets to ensure compatibility with design requirements. Confirm that the magnetic shielded structure and low DCR characteristics align with the intended application's performance needs. Check RoHS compliance status if required by regional regulations. Ensure the operating temperature range meets environmental specifications.

Fixed Inductors Selection Notes

Select this component when a shielded power inductor with low DCR is required for space-constrained designs. The 180 µH value and 1.16 A rated current suit moderate power applications. Consider the 12x12 mm footprint for PCB layout constraints. Verify saturation current limits against peak load conditions to prevent performance degradation.

Fixed Inductors Part Context

The SPQ105 series consists of SMD power inductors manufactured by CODACA Electronic Co., Ltd. These components utilize a drum core construction with magnetic shielding. The series includes various inductance values tailored for different power management needs. The SPQ105-181M represents a specific variant within this lineup optimized for balanced inductance and current handling.
