SRA-1H+

Overview

The SRA-1H+ is a double-balanced mixer manufactured by Mini-Circuits, designed for RF and IF applications. It operates within a frequency range of 500 kHz to 500 MHz. The device utilizes a surface-mount package suitable for automated assembly. Key electrical specifications include an operating temperature range from -55°C to +100°C. It features eight terminals for connection. The component is part of the broader Mini-Circuits portfolio of microwave components, supporting signal conversion functions in wireless communication and test equipment systems.

Feature Summary

• Double-balanced architecture providing high isolation between ports
• Surface-mount design for compact circuit integration
• Wide frequency coverage from UHF to VHF bands

Applications

• RF signal conversion in wireless communication systems
• IF processing in test and measurement equipment
• Frequency translation in industrial control circuits

Procurement Notes

Verify the specific datasheet version corresponding to the SRA-1H+ designation, as Mini-Circuits documentation may reference similar models like SRA-1H or SRA-1WH+. Confirm that the required frequency range up to 500 MHz aligns with system requirements. Ensure compatibility with the specified operating temperature limits of -55°C to +100°C for the intended environment. Cross-reference terminal count and package type with PCB layout constraints before finalizing procurement.

Selection Notes

Select this component when a double-balanced mixer is required for frequencies up to 500 MHz. Consider the surface-mount package for space-constrained designs. Evaluate the thermal performance against the maximum operating temperature of +100°C. Compare port isolation and conversion loss characteristics if detailed electrical data is available in the official specification sheet. Ensure the application does not exceed the maximum frequency limit.

Part Context

Mini-Circuits is a recognized manufacturer of RF, IF, and microwave components ranging from DC to 86 GHz. The company produces passive and active devices including filters, mixers, and amplifiers. The SRA-1H+ belongs to their line of frequency mixers, which are essential for signal processing in various electronic systems. These components are characterized by stable performance and compact form factors suitable for modern electronics.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Verify compatibility with existing circuit designs before considering alternative models from other manufacturers.
