Product Detailed Parameters
- Description：CMC 10UH 300MA 2LN 600 OHM SMD
- Series：SRF0602
- Mfr：Bourns Inc.
- Package：Tape & Reel (TR),Cut Tape (CT)
- Filter Type：Signal Line
- Number of Lines：2
- Current Rating (Max)：300mA
- DC Resistance (DCR) (Max)：240mOhm
- Voltage Rating - DC：50V
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 105°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Surface Mount
- Size / Dimension：0.256" L x 0.142" W (6.50mm x 3.60mm)
- Height (Max)：0.071" (1.80mm)
- Package / Case：Horizontal, 4 PC Pad
- Inductance @ Frequency：10 µH @ 10 kHz
- Impedance @ Frequency：600 Ohms @ 35 MHz
- Qualification：-
- Grade：-
Download product information
Overview
The Bourns SRF0602-100Y is a surface mount common mode choke designed for signal line filtering. It features an inductance of 10 µH at 10 kHz with a tolerance of ±50%. The component supports a maximum current rating of 300 mA and exhibits a DC resistance of 0.24 Ω. Effective frequency range spans from 35 MHz to 570 MHz, providing an impedance of 600 Ω at 35 MHz.
Feature Summary
- Provides effective common mode noise suppression for high-frequency signal lines
- Compact horizontal surface mount package design suitable for space-constrained layouts
- Engineered for stable performance within specified high-frequency operational ranges
Applications
- Signal line filtering in electronic circuits
- Common mode noise reduction in data transmission interfaces
- High-frequency interference suppression in compact devices
Procurement Notes
Verify the specific part number against official manufacturer documentation to ensure accuracy. Confirm that the required inductance value, current rating, and impedance characteristics align with the circuit design specifications. Check for any specific handling or storage requirements outlined in the datasheet before procurement.
Selection Notes
Select this component when a low-profile surface mount solution is required for signal integrity management. Ensure the operating environment does not exceed the rated current limits. Verify compatibility with automated assembly processes due to the surface mount package type.
Part Context
This component belongs to the SRF0602 series of line filters manufactured by Bourns Inc. The series offers various inductance values tailored for different filtering needs while maintaining a consistent physical footprint. These components are categorized under common mode chokes used for electromagnetic interference mitigation.
Replacement Considerations
Consult official substitution guides for compatible alternatives. Verify that any substitute matches the critical electrical parameters including inductance, current rating, and impedance profile.
